Place of Origin : Guangdong, China
Model Number : MC EV Charger
Brand Name : MAX POWER
Certification : CE
Packaging Details : Plywood boxes
Price : CN¥17,090.85/pieces 1-1 pieces
Interface Standard : CCS
Output Current : DC
Output Power : 7KW
Input Voltage : 90-265V
Product name : EV Portable Charger
Input voltage : 90-265VAC
Output voltage : 200-750VDC
Output current : 20A
Connector : Optional CCS ChadeMo GB/T Type2
IP Level : IP43
Warranty : 12 Months
Model | | MC07750DE-7KW | |
AC Input | Input Voltage | 90-265Vac | |
| AC Input Connection | L2+L3+PE(NEMA,JPS),L+N+PE | |
| Max. Input Current | 32A | |
| Frequency | 50 /60 Hz | |
| Power Factor | >0.99@full load | |
| Efficiency | 95% | |
DC Out put | Output Voltage Range | 200-750Vdc | |
| Max, Output Power | 7KW | |
| Max. Output Current | 20A | |
User Interface | OCPP 1.6 | Yes | |
| Limit power/current | Yes | |
| Interface | USB | |
Packing | Dimension | 570×190×350mm | |
| Weight | 50KG | |
Environmental | Operating Temperature | -40~85℃,25℃(TYPE) | |
| Humidity | 5%-90% RH, non-condens,ng | |
| Altitude | 2000m | |
| IP Level | IP43 | |
Mechanical | Cable Length | 5M (CHAdeMO) , 5M (CCS), 5M(GB/T) Customized acceptable | |
| Regulation | EN61851-1 | |
Regulation | Certification | CE , ROHS | |
| Charging protocol | CHAdeMO 2.0 / DIN 70121/ISD1S118/IEC618Sl-23,IEC618Sl-24 |
![]() |
CCS GB/T Type2 Portable DC 7KW EV Charger for Electric Vehicles Charging Solutions Provider Images |
